Product Features
Key design and engineering features of the 555ZY
✓
Triple voltage support: 6V, 12V and 24V — one motor covers multiple system voltages
✓
555-class motor body compatible with standard 555 motor mounting formats
✓
100% pure copper winding for efficient, reliable multi-voltage operation
✓
High torque output across the full 6–24V operating range
✓
Low operating noise suitable for consumer and light industrial environments
✓
Rated for 24/7 continuous duty in embedded drive applications
Technical Specifications
Full parameter data and dimensional drawings
📋 Performance Parameter Table
📐 Dimensional Drawing
| Parameter | Specification |
|---|
| Model | 555ZY |
| Motor Type | DC Gear Motor |
| Rated Power | See details |
| Supply Voltage | 6V / 12V / 24V |
| No-Load Speed | See details |
| Gear Ratio Range | See details |
| Output Shaft Diameter | See details |
| Frame Size | See details |
| Duty Cycle | S1 — Continuous 24/7 |
| Certification | ISO 9001 · CMA · CNAS · ILAC-MRA |
Applications
Typical industries and equipment where the 555ZY excels
📦
Vending & Dispensing
Product delivery mechanisms, coin return drives and dispensing actuators in vending machines.
🚗
Automotive Accessories
Compact actuators for power accessories, seat adjusters and cabin ventilation systems.
💡
Smart Infrastructure
Automated lighting controls, access control drives and building management actuators.
🏭
Light Industrial OEM
Custom OEM drives for compact machinery requiring versatile multi-voltage DC motor solutions.
Advantages
Why engineers and buyers choose MENG MOTOR for the 555ZY
01
Triple voltage eliminates the need for separate motor SKUs for different voltage systems
02
555-class compatibility enables drop-in replacement in existing 555 motor designs
03
ISO 9001, CMA, CNAS, ILAC-MRA certified — complete export documentation standard
04
OEM from MOQ 50 units — custom winding, shaft and voltage options available
Frequently Asked Questions
Common questions about the 555ZY
How does this 555ZY differ from motor-22 (the gear motor version)?+
Motor-22 is the 555ZY with an integrated gearbox (ratio 1:36–1:260) for reduced output speed and higher torque. This model (motor-24) is the base motor without gearbox — higher speed, lower torque, smaller package.
Can I use a gearbox with this motor?+
Yes. This motor is compatible with external gearboxes. Contact us with your required output speed and torque and we will advise on compatible gearbox options.
What is the current draw at 12V rated load?+
Current draw depends on the load. Please contact us with your load specification and we will provide the current draw data for your operating point.
Is this motor RoHS and REACH compliant?+
Yes. All MENG MOTOR products comply with RoHS and REACH requirements. Compliance documentation is available upon request for export orders.
